Unit 1, outstanding efficiency: (1) isothermal compression technology make the unit efficiency greatly enhance - built-in frequency conversion technology energy saving up to 35%. (2) the unique pressure bandwidth control technology for energy conservation and better have no hydraulic suspension bearing friction loss. (3) direct drive technology to reduce energy consumption. (4) built-in dryer can reduce post-processing pressure drop loss.
2, high quality air: (1) the ISO 8573 - lClass0 air quality. (2) built-in person to ensure that the pressure dew point < 3 oc.
(3) anticorrosive material: aluminum bronze alloy rotor shell, stainless steel shaft, pipeline system and the separation of barrels. (4) variable frequency drive, start a smooth, no impact.
No risk grade 3, Class 0: : (1) Class 0 represents high quality of compressed air. (2) LUW series water oil-free screw compressor with Class 0 without oil certification (ISO 8573-1 Class 0 Ed. 3, 2010 performance specification). (3) LUW series without oil hydraulic screw machine is suitable for the harsh compressed air quality requirements.
4, saving energy control system: (1) the instantaneous pressure record tracking bandwidth to ensure reasonable pressure function, reduce the average pipe network pressure. (2) built-in energy-saving closed-loop feedback logic to ensure that the energy efficiency calculation, compressed air quality better built-in networking control function. (3) double pressure switch control mode.
5, energy saving from the variable frequency technology: (1) occupy the compressor energy costs nearly five years 70% of the life cycle cost. (2) reduce the compressed air energy costs to reduce the comprehensive cost of the compressed air system is critical. (3) LUW water oil-free screw compressor can make your compressed air energy costs by 30%.
